Callisto-Moon of Jupiter

Callisto's density is very small. It makes up 33% of Mercury's density. This basic figure can give a preliminary indication of its internal composition. In terms of photographic coverage, it was photographed by the two Voyager spacecraft, the Galileo spacecraft, and New Horizons, which transmitted several photographs of it to Israel on its way to Pluto.

Callisto. Photo: NASA
Callisto. Photo: NASA

Callisto, the most distant of the Galilean moons, has a diameter of 4840 km and is the same size as the planet Mercury, 4878 km. The density of the latter is 5.44 g/cm1.8 compared to Callisto's density of 60 g/cm33. Mercury is the body with the highest density among the bodies surrounding the Sun and its nucleus is very large. Its core mass is XNUMX% of the mass of the planet and occupies a large part of its volume. Callisto's density is very small. It makes up XNUMX% of Mercury's density. This basic figure can give a preliminary indication of its internal composition. The first impression received is that the size of the core is hundreds of kilometers and that it has large aquifers of water and has a large content of low-density minerals. Therefore, some of the rocks also have a low density. In terms of photographic coverage, it was photographed by the two Voyager spacecraft, the Galileo spacecraft, and New Horizons, which transmitted several photographs of it to Israel on its way to Pluto.


Callisto has a thin atmosphere of CO2. The atmospheric pressure is -1210X7.5 bar and the temperature near the ground is -123°C. In terms of density, it is actually an exosphere like Mercury's atmosphere, although it has a different chemical composition and the temperature differences are very large. Several possibilities have been put forward to explain this atmosphere. According to one explanation, gas burst out of the interior of the moon and evidence of sublimation of the surface was indeed found. A large release of gas during the stages of formation of substances containing it or by the passage of aqueous substances of primitive carbonaceous compounds. According to both explanations, the atmosphere and the CO2 from the ground mix on the surface and not from an internal source. Interaction between ultraviolet radiation and charged particles can create and release CO2 from internal materials or carbon-containing materials present on the surface. Chemical production of CO2 and other volatiles can occur following collisions of large bodies with the lunar soil and following the bombardment of micrometeorites. Another source could be the continuous growth of CO2 from cometary matter (1).


According to the photographs that were broadcast to Israel, it appears that Callisto lacks geological characteristics known on the surface of the Earth and other bodies in the solar system such as canyons, volcanoes, channels, etc. It is possible that there was geological activity on it in the past, but the evidence for this is not clear. The geological changes that left their mark on it are craters and they make up 70% of its surface (2). Most of the craters are less than 100 km in diameter. The distribution of the craters of craters with a diameter greater than 100 km is as follows - 32 craters with a diameter of 100-200 km, 3 craters with a diameter of 200-300 km, 2 craters with a diameter of 300-400 km, 1 crater with a diameter of 410 km, 1 crater with a diameter of 660 km, 1 crater with a diameter of 980 km (3).

Close-up photographs taken when the Galileo spacecraft passed at a distance of 138 km from it and craters with a diameter of 3 meters were recorded, although their number is less than they thought. Indented hills were found near one of the craters. They look like ice thrown out of the ground as a result of the impact of a large body that hit the surface (4). Many of the craters are bright. The source of this brightness is the material that was excavated in the lunar soil when the craters were formed, a material that contains large amounts of water. The end result is powdery material that covers large parts of the surface (5). Some of the young craters are 40% as deep as the craters of the Earth's moon (2), which indicates a low topography. Callisto's relief height is similar to that of Mercury.

Many of the craters have depressions in their center. Probably a reaction of ice to the process creating the injury. The bottom structure of young craters changes with their larger diameter. Small craters are deep and their shape is concave. Large craters are shallow and their bottom is relatively flat. Ancient craters, their bottom is almost at the same height as their surroundings. Despite the heavy bombardment of bodies that created the craters, the languages ​​of many of them were preserved (7).

The largest of the craters is the Valhalla crater. It is a multi-ring crater, in the center of which is a bright area with a diameter of 600 km and it is surrounded by concentric rings with a diameter of 3,000-4,000 km. The bright material in the center was probably created due to digging and throwing "cleaner" ice that was under the ground and "Impact Melts" filled the crater after its formation. The concentric rings are cracks created due to the impact (2,8).

The second large crater that also has concentric rings is the Asgard crater with a diameter of 370 km. The concentric rings reach up to a distance of 1900 km from its center. In the center are also bright areas and lumps of ice and what caused their formation is unclear (9) as in the Valhalla crater the rings were formed following an impact that created it they were formed by a tectonic process. You can see craters on the rings, which means they were created later. In the northern part of the Asgard basin is the Burr crater with a diameter of 71 km and from it emerge rays that cover the northern and outer segment of the concentric rings (10). This concentricity of the rings is also found in the Chloris Basin on Mercury.

Two unique craters are the Doh crater which is 55 km in diameter and has a domed relief in the center (11) and the Har crater which is 50 km in diameter and also has a domed relief in the center (12). This is not a shock wave following the formation of craters that creates a bulge in their center. It seems to be a completely different process. These formations resemble bubbles formed in boiling water. It is possible that convection currents developed in these places long after the formation of the craters. These currents raised the floor of the crater. It is likely that there was a gas leak in these places and the density in them is lower than the global density of the moon. They are probably made of materials rich in water ice. A question that can be asked is why with the cooling, these formations did not sink? One possibility is that these processes took place not long ago (in geological terms, perhaps thousands or tens of thousands of years). A second possibility is that the convection currents are still active and occasionally push additional gases from below and strengthen the configuration so that it does not collapse.

Rockfalls can be seen in several photographs. These are rocks that broke away from the sides of craters and deteriorated to their floor (13,14,15). An explanation put forward for this phenomenon is meteorites that hit the environment of these craters, creating seismic activity that resulted in the detachment of the rocks and their deterioration. The result, the exposure of internal parts of the rock and most likely they were also exposed to the sun's radiation and it acted on them. In future flights to Callisto, spacecraft will be equipped with cameras with greater resolutions and it will be possible to examine these craters in more detail. The inspection of these will be more thorough if spaceships are landed in these places.


These are arrays of concentric fragments that appear as topographic remnants around circular shapes with high light reflectance indicating that they were originally deformed impact craters and are probably very ancient. Craters with a "black halo" are explained as craters that dug into the light material and they indicate that the light material that forms the Palimpsets is at most 1 km thick. At least 11 palimpsests have been identified on Callisto. They have almost no topographic prominence and are difficult to map accurately. Younger palimpsets within the multi-ring basins such as Valhalla and Asgard are easier to identify. Their shape is between elliptical and circular (2).

Button configurations

One of the interesting phenomena observed on Callisto is button-like formations that are 80-100 meters high. They are made of water ice and also contain some dark dust. As the ice evaporates the dark matter slides down, moves and accumulates at low levels. Over time all the ice will evaporate until it completely disappears from the impact craters. At the bottom of one of the photos you can see that the evaporation has stopped in the planes that appear in it (16).


Due to the thinness of the atmosphere, there are no winds on Callisto, yet in several photographs it is possible to notice that erosive activity has occurred on its surface. In photo 0876PIA some of the craters do not have a sharp structure on their sides. The large craters visible in it, one of them with a diameter of 60 km and the other with a diameter of 30 km (17). Another photograph taken from a distance of 138 km from the ground shows a light and spiky area with dark dust. It is seen that this area has undergone a slow but active process of erosion. The explanation for this is that part of the ice sublimated and left behind the dust that was attached to it. The accumulation of dust absorbs enough heat from the sun to heat the surrounding ice and allows the sublimation process to continue (18).

Internal structure

Callisto's gravity measurement showed that it probably has a homogeneous internal structure. 60% of it is rock and 40% compressed water ice. It seems that within Callisto there is no internal separation of matter. This estimate is consistent with the fact that the Moon has no internal magnetic field, indicating that it has not experienced a phase of high heating necessary to separate the rock and metallic elements from the light ice (19).

ocean water

The researchers noticed that each time the spacecraft passed by Europa and Callisto, the strength and direction of Jupiter's magnetic field changed slightly. Both moons appear to generate electric currents near their surface as they pass through Jupiter's magnetic field, much like an electric motor generates an electric current. In order for there to be an electric current there must be some kind of conductor. The water ice that covers Europa and Callisto will not cause this because we are not a good conductor. Salt water, on the other hand, is a good conductor, which has led to the line of thought that beneath the surface of Callisto there is an ocean. While ionized molecules in the atmosphere are certainly a good conductor, Callisto's atmosphere is too thin to create this effect. It is estimated that the ocean of water is 16 km below the surface of the earth. The obvious question is what heats this water? A possible answer is radioactive elements in the nucleus (20). Geological evidence that can support this hypothesis is the Valhalla basin. Such a layer of water would have dissipated the shock waves created by the impact that created this basin. The lack of hills and grooves on the other side of Callisto (Antipode) is consistent with this possibility (21). In the Antipode of large craters on the Moon and Mercury, grooves and hills called Antipode Terrein are found and are attributed to shock waves originating from the craters on the other side of these bodies (22).


Around Callisto there are plasma waves, although, unlike Ganymede, it does not have a magnetosphere or an internal magnetic field. The electron density around this moon is higher than the magnetic field of Jupiter at this distance from the planet itself, which indicates that Callisto is a definite source of a plasma generator created in this place. Callisto's thin atmosphere likely generates this plasma. It is similar to the hydrogen cloud surrounding Ganymede since the electron density in both moons is similar (19).


1. Carlson RW-"A tenuous Carbon Dioxide atmosphere on Jupiter's moon Callisto"
Science Vol. 283 pp. 820-821 5.2.1999

2. Schenk PM- "The geology of Callisto" Journal Of Geophysical Research Vol. 100 no. E9 pp. 19, 023- 19, 040 25.9.1995

3. "Callisto craters by descending diameter (km)

4."Galileo flyby reveals Callisto's bizarre landscape" 22.8.2001

5.PIA09258: Capturing Callisto

6.Rogus FH-The giant planet Jupiter Cambridge University Press 1995 pp. 383-384

7. Strom RG et al - "Crater population on Ganymede and Callisto" Journal Of Geophysical Research Vol. 86 A10 pp. 8659-8674 30.12.1981

8.PIA091298: Global variation on Callisto

9.PIA01629 : Textured terrain Callisto's Asgard basin

10.PIA00517: Asgard impact structure on Callisto

11.PIA01648: Impact craters on icy Callisto Doh crater and Asgard

12.PIA01054: Har crater on Callisto

13.PIA00745: Callisto's equatorial region

14.PIA01095: Landslides on Callisto

15.PIA01222: Mass wasting in craters near the south pole of Callisto

16."2001 images releases Jupiter's moon Callisto" 22.8.2001

17.PIA00876: Craters near the south pole of Callisto

18."Gallileo flyby reveals Callisto's bizarre landscape" 22.8.2001

19. "Galileo spacecraft explores Jupiter's moon Callisto: 15.5.1997 recurssors/astronom/galileo/calisto/nature.htm

20. Kenneth C.-A sea on Jupiters Call Isto” 23.10.1998

21. "Opposite side of Callisto from Valhalla impact" 29.11.2001

22."ocean inside Jupiter moon may have cushioned impact" 29.11.2001
